Grade:
Width:
Weight:
Thickness:
Abrasion:
Other Specs:

9
54 in
17 oz
0.8 mm
400,000 DR
Face 100% PVC Free Polyurethane
Backing 100% Polyester
Weight 17.0 oz. per linear yd
Thickness 0.80 mm
Width 54″
Directional Yes
Railroaded No
Additional Attributes
Finish/Treatment Cleangene
Antibacterial Yes
Antimicrobial Yes
Bleach Cleanable Yes
Ratio: 75% Water / 25% Bleach Solution
Mildew Resistant Yes
Sulfide Stain Resistant Yes
Performance Characteristics
Abrasion Resistance (ASTM D4157) 400,000+ double rubs
Tensile Strength (CFFA-17) Warp: 146.0 lbs.
Fill: 80.0 lbs.
Tear Strength (CFFS-16) Warp: 11.2 lbs.
Fill: 12.4 lbs.
Seam Slippage Warp: 60.3 lbs.
Fill: 43.8 lbs.
Colorfastness to Crocking (AATCC 8) Dry: 5.0
Wet: 5.0
UV Resistance (CFFA-2) 200 hours
Adhesion (CFFA-3) Warp: 18.8 lbs.
Fill: 13.45 lbs.
Blocking (CFFA-4) 2
Cold Crack (CFFA-6) -20° F
Hydrolysis 7 Weeks
Flammability*
CAL TB 117-E Passes
NFPA 260 Class 1
UFAC Class 1
ASTM E-84 Class A or 1
BIFMA CS-191-53, Sec. 3 Passes
BIFMA Upholstery, Sec. 4 Passes
Int’l Maritime Org., IMO A.652(16) 8.2 Passes
