Grade:
Thickness:
Weight:
Abrasion:
Other Specs:

7
1.09 mm
30 oz
100,000 DR
Face 100% Vinyl
Backing Hi-Loft2™ 100% Polyester
Repeat H – 3.625″
V – 3.5″
Directional Yes
Railroaded No
Additional Attributes
Finish/Treatment Permablok3®
Silverguard®
Permablok3® Yes
Antibacterial Yes
Antimicrobial Yes
Bleach Cleanable Yes
Ratio: 75% Water / 25% Bleach Solution
Mildew Resistant Yes
Sulfide Stain Resistant Yes
Performance Characteristics
Abrasion Resistance (ASTM D4157)
Tensile Strength (CFFA-17) Warp: 123.0 lbs.
Fill: 87.0 lbs.
Tear Strength (CFFA-16) Warp: 20.0 lbs.
Fill: 20.0 lbs.
Seam Slippage Warp: 12.0 lbs.
Fill: 9.2 lbs.
Colorfastness to Crocking (CFFA-7) Dry: Excellent
Wet: Excellent
UV Resistance (AATCC TM 16E) 1000 hours
Adhesion (CFFA-3) Warp: 3.3 lbs.
Fill: 3.3 lbs.
Cold Crack (CFFA-6) -10° F
Flammability*
CAL TB 117-E Passes
NFPA 260 Class 1
UFAC Class 1
BIFMA X5.7 Class A & 1
Boston Fire Code Passes
Federal Aviation Specification Passes
Federal Specification Passes
Int’l Maritime Org., IMO A.652(16) 8.2 Passes
Int’l Maritime Org., IMO A.652(16) 8.3 Passes
FMVSS 302 Passes
Port Authority of NY/NJ Passes
Please refer to Detailed Cleaning Instructions above.
