Grade:
Thickness:
Weight:
Abrasion:
Other Specs:

7
1.22 mm
30.8 oz
100,000 DR
100% Vinyl
Ink Resistant Technology
Bleach Cleanable: 90% Water / 10% Bleach Solution
Meets or exceeds all ACT® Standards
Fabric Specifications
Face 100% Vinyl
Backing 100% Polyester
Directional Yes
Railroaded No
Additional Attributes
Finish/Treatment MGX MorGuard Xtreme
Antibacterial Yes
Antimicrobial Yes
Bleach Cleanable Yes
Ratio: 90% Water / 10% Bleach Solution
Mildew Resistant Yes
Performance Characteristics
Abrasion Resistance (Wyzenbeek)
Tensile Strength (ASTM D751) Warp: 110.0 lbs.
Fill: 75.0 lbs.
Tear Strength (CFFA-16) Warp: 8.0 lbs.
Fill: 10.0 lbs.
Colorfastness to Crocking (Fed Std 191A 5651) Dry: Good
Wet: Good
UV Resistance (ASTM G153-00a) 1000 hours
Adhesion (ASTM D751) Warp: 3.5 lbs.
Fill: 3.5 lbs.
Blocking 2 max
Cold Crack -25° F
Flex (Newark (W-Flex)) 30,000+ cycles
Flammability*
CAL TB 117-E Passes
NFPA 260 Class 1
UFAC Class 1
FMVSS 302 Passes
Port Authority of NY/NJ Not Tested
Please refer to Detailed Cleaning Instructions above.
