Grade:
Width:
Weight:
Thickness:
Abrasion:
Other Specs:

7
54 inches
29 oz
1.2 mm
500,000 DR
Face 100% Vinyl
Backing 100% Polyester
Directional No
Railroaded No
Additional Attributes
Finish/Treatment ResilienceSR
Antibacterial Yes
Antimicrobial Yes
Bleach Cleanable Yes
Ratio: 90% Water / 10% Bleach Solution
Mildew Resistant Yes
Sulfide Stain Resistant Yes
Performance Characteristics
Abrasion Resistance (ASTM D4157) 500,000 double rubs
Tensile Strength (CFFA-17) Warp: 142.0 lbs.
Fill: 97.0 lbs.
Tear Strength (CFFA-16) Warp: 7.9 lbs.
Fill: 7.7 lbs.
Seam Slippage Warp: 58.0 lbs.
Fill: 41.0 lbs.
Colorfastness to Crocking (AATCC 8) Dry: 5.0
Wet: 5.0
UV Resistance (CFFA-2) 500 hours
Adhesion (CFFA-3) Warp: 12.1 lbs.
Fill: 9.800000000000001 lbs.
Blocking (CFFA-4) 2
Cold Crack (CFFA-6) -20° F
Flex (CFFA-10) 25,000 cycles
Flammability*
CAL TB 117-E Passes
NFPA 260 Class 1
UFAC Class 1
ASTM E-84 Class A or 1
BIFMA CS-191-53, Sec. 3 Passes
BIFMA Upholstery, Sec. 4 Passes
Boston Fire Code Passes
Int’l Maritime Org., IMO A.652(16) 8.2 Passes
Int’l Maritime Org., IMO A.652(16) 8.3 Passes
FMVSS 302 Passes
Port Authority of NY/NJ Passes
Recommended Cleaning
Please refer to Detailed Cleaning Instructions above.
